ABOUT THE SYSTEM SYSTEM FRONT VIEW
6
System Front View
Figure 2. 2.5” Storage Drive System Front View
10 Riser assembly (CPU0) Support PCIe add-on card installation with riser feature.
11 PSU assembly Redundant power supply unit assembly
12 SuperCap carrier Housing SuperCap using in SAS mezzanine card or SAS add-on card
13 DIMM slots
(12) DDR4 DIMM slots per CPU
14 Fan module (8) System fan modules
Table 3: Front View
NO.NAME DESCRIPTIONS
1 Thumb screw Secure the system to rack frame
2 2.5” storage drive tray Housing up to twelve 2.5” storage drive (15mm):
3USB port Connect to USB device
4 Asset tag Record serial number or other important information
5 Front control panel
See Front Control Panel LEDs on page 12 for further information.
