14
English
7. Stopper (Optional accessory) for precision cutting
The stopper facilitates continuous precision cutting in lengths of
10" to 16-1/2" (255 mm to 420 mm). To install the stopper, attach it
to the holder with the 6 mm wing bolt as shown in Fig. 13.
PRACTICAL APPLICATIONS
WARNING: * To avoid personal injury, never remove or place a workpiece on the table while the tool
is being operated.
* Never place your limbs inside of the line next to warning sign while the tool is being
operated. This may cause hazardous conditions (see Fig. 14).
1. Switch operation
The trigger switch lock-off button is designed to prevent inadvertent
operation of the power tool. To operate the power tool, it is
necessary to first fully insert the lock-off button into the hole on
the handle as shown in Fig. 15.
The trigger switch will not operate unless the lock-off button has
been pushed in.
When the trigger switch is released, the power goes off and the
lock-off button automatically returns to its initial position, locking
the trigger switch.
WARNING: Always remove the lock-off button from the handle when the power tool is not in
use. This will ensure that the power tool cannot be turned on accidentally or by
someone (especially a child) who is not qualified to use the power tool. If the lock-off
button is left in the handle, serious personal injury can result. Since the lock-off button
fits rather tightly, it may be necessary to turn it to the left and right during mounting
and removing.
Fig. 14
Fig. 15
Lock-off
Button
Hole
Trigger
Switch
Line LineWarning Sign Warning Sign
Handle
Fig. 13
Workpiece
6 mm
Wing Bolt
Stopper
