30
(4) Lift the lower guard and mount the saw blade.
WARNING: When mounting the saw blade, confirm that the rotation indicator mark
on the saw blade and the rotation direction of the gear case (see Fig. 1)
are properly matched.
(5) Thoroughly clean washer (D), collar and the bolt, and install them onto the saw
blade spindle.
(6) Press in the spindle lock and tighten the bolt by turning it to the left by standard
accessorie’s wrench (10mm box wrench) as indicated in Fig. 50-c.
CAUTION:*A dust guide is installed inside behind the gear case.
When removing or installing the saw blade, do not make contact with
the dust guide. Contact may break or chip saw blade tips.
* Confirm that the spindle lock has returned to the retract position after
installing or removing the saw blade.
* Tighten the bolt so it does not come loose during operation.
Confirm the bolt has been properly tightened before the power tool is
started.
2. Dismounting the saw blade
Dismount the saw blade by reversing the mounting procedures described in paragraph
1 above.
The saw blade can easily be removed after lifting the lower guard.
CAUTION: Never attempt to install saw blades larger than 262mm (10") in diameter.
Always install saw blades that are 262mm (10") in diameter or less.
MAINTENANCE AND INSPECTION
WARNING: To avoid an accident or personal injury, always confirm that the trigger
switch is turned OFF and the power plug has been disconnected from the
receptacle before performing any maintenance or inspection of this tool.
1. Inspecting the saw blade
Always replace the saw blade immediately upon the first sign of deterioration or damage.
A damaged saw blade can cause personal injury and a worn saw blade can cause
ineffective operation and possible overload to the motor.
CAUTION: Never use a dull saw blade. When a saw blade is dull, its resistance to
the hand pressure applied by the tool handle tends to increase, making it
unsafe to operate the power tool.
