English
11
2. Battery Charger (UC18YRSL)
Fig. 2
SPECIFICATIONS
1. Cordless Circular Saw (C18DSL)
2. Battery Charger (UC18YRSL)
Pilot lamp
Cord
Nameplate
Guide rail
Motor DC motor
No-load speed 3,400/min
Max. Cutting Depth 2-1/4” (57 mm)
Blade Size 6-1/2” (165 mm) D × 5/8” (15.9 mm) H × 1/16” (1.6 mm) T
Model BSL1830
Battery
Type Lithium – ion battery
Voltage DC 18V
Capacity 3 Ah
Light Bulb 12V, 5W
Weight 7.1 lbs. (3.2 kg)
Input power source Single phase: AC120V 60Hz
Charging time
(At a temperature of 68°F (20°C))
Approx. 45 min.
Charging voltage DC 14.4V 18V
Charging current DC 3.5A
Weight 1.3 lbs. (0.6 kg)
NOTE: The charging time may vary according to ambient temperature and power source voltage.
01Eng_C18DSL_US 8/8/08, 09:4211
