MECHANICAL PARTS LIST
-53-
Part No Qty Description
YZ030121T0C001 1 POLYFOAM END CAP.R&L (TOP&BOTTOM) SMALL
YZ040400005400 1 POLYBAG W100 X H95cm
YZ040409014003 1 POLYBAG 9" X 14" X 0.04 MM (PO) W/PE
YZ041505506510 1 BUBBLE BAG 5.5" X 6.5"
YZ060220021800 3 QC PASSED LABEL (WHITE)
YZ060220121800 1 QC PASSED LABEL (GOLD)
YZ100221T07101 1 BACK CABINET DARK GREY #DG001 94V-0
YZ100721T0C001 1 FRONT LENS - TRANSPARENT (PC)
YZ100821T0C001 1 CONTROL KEYS KNOB - #TS003
YZ100921T0C001 1 POWER KNOB - #TS003
YZ101929F10002 3 WIRE HOLDER DIA. 15 MM
YZ103929F10002 2 HANDLE PLATE
YZ120521T04001 1 INLAY - RCA JACK X 12 STEREO(3P31)
YZ130521T0B001 4 TAPE 33 X 20 X 0.15mm
YZ130621600004 3 TAPE LABEL 350 X 25 X 1 MM
YZ131229TK0001 4 RUBBER PAD
YZ132029F10001 2 ADHESIVED TAPE CUSHION 105 X 50 X 1 MM
YZ150202829900 4 CRT MTG. BRACKET
YZ152382180001 8 STAPLE (SILVER)
YZ190100821610 1 POWER KNOB SPRING - DIA. 0.6 SPRING WIRE
YZ190200015010 2 GROUNDING WIRE SPRING- FOR KNITTING WIRE
YZ240100040000 11 CABLE TIE - L = 4"
YZ240100080001 4 CABLE TIE - L = 8" W = 2.5MM
YZ26BA030080N0 10 BA 3 X 8
YZ26BA030100N0 2 BA 3 X 10
YZ26BA035120N0 4 BA 3.5 X 12
YZ26BA035160B0 3 BA 3.5 X 16 (BLACK)
YZ26BA040120B0 1 BA 4 X 12 (BLACK)
YZ26BA040200B0 6 BA 4 X 20 (BLACK)
YZ26BA040200N0 12 BA 4 X 20
YZ26KA026080B0 3 KA 2.6 X 8 (BLACK)
YZ27MHM60A0N05 4 M6 NUT
YZ2801030810F0 1 FIBRE WASHER - DIA. 3 X 8 X 1 MM
YZ2801031412F0 4 FIBRE WASHER - DIA. 3 X 14 X 1.2 MM
YZ2801062220R0 4 RUBBER WASHER - DIA. 6 X 22 X 2 MM
YZ2801062230R0 4 RUBBER WASHER - DIA. 6 X 22 X 3 MM
YZ380105000000 60 HEAT-SHRINKABLE TUBE - DIA. 5.0MM
YZ380306000000 10 PVC TUBE - DIA. 6.0MM
YZ101321NS0002 1 ANTENNA HOLDER - DARK GREY #DG001
YZ26BA030100N0 1 BA 3 X 10
YZ100121T0C102 1 FRONT CABINET - #TS003/#NB001 3P31 94V-0
YZ010021T0C000 1 CARTON BOX NO PAINTING SMALL
FOR REFERENCE ONLY

Hitachi C21-F880S Specifications

General

Display Technology	CRT
Aspect Ratio	4:3
Screen Size	21 inches
Video Input	Composite
Audio Input	RCA
Input Voltage	220-240V AC
