(7) Tightening torque of screws and bolts:
•
D4 Tapping Screws [4] [5] [15] ([7]) ([8]) ([14])
•
Machine Screw M4 x 12 [46] ([49])
•
M4 Screw [18] [57] [68] ([20]) ([60]) ([71])
•
Seal Lock Flat Hd. Screw M5 x 10 [50] ([53])
•
Hex. Socket Hd. Bolt M5 x 14 [72] ([75])
•
Hex. Socket Hd. Bolt (W/Flange) M5 x 12 [51] ([54])
•
Lever Bolt [62] ([65])
10-3. Wiring Diagrams
The wiring is in accordance with Fig. 18 (CJ 120V) and Fig. 19 (CJ 120VA).
1.96 0.49 N
•
m [20 5 kgf
•
cm, 1.4 0.4 ft-lbs.]
1.96 0.49 N
•
m [20 5 kgf
•
cm, 1.4 0.4 ft-lbs.]
2.45 0.49 N
•
m [25 5 kgf
•
cm, 1.8 0.4 ft-lbs.]
3.92 --- 5.88 N
•
m [40 --- 60 kgf
•
cm, 2.9 --- 4.3 ft-lbs.]
2.45 0.49 N
•
m [25 5 kgf
•
cm, 1.8 0.4 ft-lbs.]
3.92 --- 5.88 N
•
m [40 --- 60 kgf
•
cm, 2.9 --- 4.3 ft-lbs.]
3.92 --- 5.88 N
•
m [40 --- 60 kgf
•
cm, 2.9 --- 4.3 ft-lbs.]
Fig. 18 CJ 120V
Noise suppressor
Switch
Armature
Controller ass'y
Stator coil
Choke coil
Stator coil
Choke coil
Fig. 19 CJ 120VA
Noise suppressor
Switch
Armature
Controller ass'y
Stator coil
Choke coil
Choke coil
Stator coil

Hitachi CJ 120V Specifications

General

Type	Jigsaw
Voltage	120V
Stroke Length	1 inch
Bevel Capacity	45 Degrees
Category	Power Tool
Strokes per Minute	850 - 3, 000
