4
English
STANDARD ACCESSORIES
(1) Blade (No.1, No.3, No.5) [CR10V]................ 1 each
Blade (No.1) [CR12, CR12V] ....................................1
Refer to tables 1 and 2 for use of the blades.
(2) Hexagonal bar wrench.............................................1
(3) Case [CR10V, CR12V] ...............................................1
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
(1) No. 2 Blade
(2) No. 4 Blade
(3) No. 6 Blade
(4) No. 7 Blade
(5) No. 8 Blade
(6) No. 9 Blade
(7) No. 95 Blade
(8) No. 96 Blade
(9) Cut-off Guide for Pipe
Refer to tables 1 and 2 for use of the blades.
Optional accessories are subject to change without notice.
APPLICATIONS
䡬 Cutting pipe and angle steel.
䡬 Cutting various lumber.
䡬 Cutting mild steel plate, aluminum plate, and copper
plate.
䡬 Cutting synthetic resins, such as phenol resin and
vinyl chloride.
For details refer to the section entitled “Selection of
blades”
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, which could cause
a serious accident.
Model CR10V CR12 CR12V
Voltage (by areas)* (110V, 115V, 120V, 127V, 220V, 230V, 240V)
Power Input 720W*
Capacity Mild Steel Pipe: O.D. 115 mm
Vinyl Chloride Pipe: O.D. 115 mm
Wood: Thickness 100 mm
Mild Steel Plate: Thickness 13 mm
No-Load Speed 700 – 2200/min 2500/min 800 – 2500/min
Stroke 26 mm 30 mm
Weight (without cord and side handle) 3.6 kg 3.2 kg
*Be sure to check the nameplate on pruduct as it is subject to change by areas.
SPECIFICATIONS
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Adjusting the blade operating speed
(CR10V, CR12V)
The machine is equipped with an electric control
circuit which enables non-step speed control. To
adjust the speed, turn the dial shown in Fig. 1.
When the dial is set to “1”, the saber saw operates
at the minimum speed (CR10V: 700/min, CR12V:
800/min). When the dial is set to “5”, the saber saw
operates at the maximum speed (CR10V: 2200/min,
CR12V: 2500/min). Adjust the speed according to
the material to be cut and working efficiency.
5. Adjusting the orbital operation (CR10V)
(1) This machine employs orbital operation which moves
the blade back and forth, as well as up and down.
Set the change lever shown in Fig 2 to “1” to
minimize the orbital operation. The orbital operation
can be selected in 3 steps from “I” to “III”.
(2) For hard material, such as a steel plate, etc., decrease
the orbital operation. For soft material, such as
lumber, plastic, etc., increase the orbital operation
to increase work efficiency. To cut the material
accurately, decrease the orbital operation.
6. Mounting the blade
Insert the blade between the plunger and the blade
holder, and tighten the set screw with the accessory
hexagonal bar wrench, as shown in Fig. 3.
When inserting the blade, ensure that the projection
part of the blade holder is properly fitted to the
matching hole in the blade, as shown in Fig. 4.
CAUTION
A loosened set screw may cause the blade to be
damaged. Always ensure that the set screw is
securely tightened.
7. Moving the base
Loosen the set screw and move the base forward,
as shown in Fig. 5. Tighten the set screw slightly,
ensure the base does not move back and forth, and
firmly tighten the set screw. Ensure that the base
does not contact the blade.
8. Confirm the blade clamping
Ensure that the blade setscrew is securely tightened.
To Next Page
