7
English
SPECIFICATIONS
Voltage (by areas)*
(110 V, 115 V, 120 V, 127 V, 220 V, 230 V, 240 V)
Power Input 1010 W*
Capacity Mild Steel Pipe: O.D. 130 mm
Vinyl Chloride Pipe: O.D. 130 mm
Wood: Depth 300 mm
Mild Steel Plate: Thickness 19 mm
No-Load Speed 0 – 2800/min
Stroke 29 mm
Weight (without cord) 3.3 kg
* Be sure to check the nameplate on product as it is subject to change by areas.
PRECAUTIONS ON USING RECIPROCATING
SAW
Prior to cutting into walls, ceilings or fl oors, ensure there
are no electric cables or conduits inside.
STANDARD ACCESSORIES
(1) Blade (No. 341) .............................................................1
(2) Case .............................................................................1
(3) Hexagonal bar wrench .................................................1
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
(1) No. 1 Blade (12) No. 103 Blade
(2) No. 2 Blade (13) No. 104 Blade
(3) No. 3 Blade (14) No. 105 Blade
(4) No. 4 Blade (15) No. 106 Blade
(5) No. 5 Blade (16) No. 107 Blade
(6) No. 8 Blade (17) No. 108 Blade
(7) No. 9 Blade (18) No. 121 Blade
(8) No. 95 Blade (19) No. 131 Blade
(9) No. 96 Blade (20) No. 132 Blade
(10) No. 101 Blade (21) Cut-off guide for pipe
(11) No. 102 Blade
○ (1) – (9) : HCS Blades (HCS : High speed Carbon
Steel)
○ (10) – (20) : Bl-METAL Blades
Refer to Table 1, 2, 3 and 4 for use of the blades.
Optional accessories are subject to change without notice.
APPLICATIONS
○ Cutting pipe and angle steel.
○ Cutting various lumbers.
○ Cutting mild steel plates, aluminum plates, and copper
plates.
○ Cutting synthetic resins, such as phenol resin and vinyl
chloride.
For details refer to the section entitled “SELECTION OF
BLADES”.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirement specifi ed on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position. If
the plug is connected to a receptacle while the power
switch is in the ON position, the power tool will start
operating immediately, which could cause a serious
accident.
3. Extension cord
When the work area is removed from the power source,
use an extension cord of suffi cient thickness and rated
capacity. The extension cord should be kept as short as
practicable.
4. Dust produced in operation
The dust produced in normal operation may aff ect
the operator’s health. To wear a dust mask is
recommended.
5. Mounting the blade
This unit employs a detachable mechanism that
enables mounting and removal of saw blades without
the use of a wrench or other tools.
(1) Turn on and off the switching trigger several times so
that the lever can jump out of the front cover completely.
Thereafter, turn off the switch and unplug the power
cord. (Fig. 1)
CAUTION
Be absolutely sure to keep the switch turned off and the
power cord unplugged to prevent any accident.
(2) Push the lever in the direction of the arrow mark shown
in Fig. 2 marked on the lever. (Fig. 2)
(3) Insert the saw blade all the way into the small slit of the
plunger tip with the lever pushing. You can mount this
blade either in the upward or downward direction. (Fig.
3, Fig. 4)
(4) When you release the lever, the spring force will return
the lever to the correct position automatically. (Fig. 5)
(5) Pull the back of the saw blade two or three times by hand
and check that the blade is securely mounted. When
pulling the blade, you will know it is properly mounted if
it clicks and the lever moves slightly. (Fig. 6)
CAUTION
When pulling the saw blade, be absolutely sure to pull it
from the back. Pulling other parts of the blade will result
in an injury.
