Hitachi CR13V2 User Manual

9
English
4. Plunge cutting
With this tool, you can perform plunge cutting on
plywood panels and thin board materials. You can
carry out pocket cutting quite easily with the saw blade
installed in reverse as illustrated in Fig. 22, Fig. 24, and
Fig. 26. Use the saw blade that is as short and thick as
possible. We recommend for this purpose that you use
BI-METAL Blade No. 132 mentioned in Table 2. Be sure
to use caution during the cutting operation and observe
the following procedures.
(1) Press the lower part (or the upper part) of the base
against the material. Pull the switch trigger while
keeping the tip of the saw blade apart from the material.
(Fig. 21, Fig. 22)
(2) Raise the handle slowly and cut in with the saw blade
little by little. (Fig. 23, Fig. 24)
(3) Hold the body fi rmly until the saw blade completely cuts
into the material. (Fig. 25, Fig. 26)
CAUTION
○ Avoid plunge cutting for metallic materials. This can
easily damage the blade.
○ Never pull the switch trigger while the tip of the saw
blade tip is pressed against the material. If you do so,
the blade can easily be damaged when it collides with
the material.
○ Make absolutely sure that you cut slowly while holding
the body fi rmly. If you apply any unreasonable force to
the saw blade during the cutting operation, the blade
can easily be damaged.
5. Cut off guide for cutting pipe (optional accessory)
Product
Cutting
appalication
Blade
used
Code No.
Cut-off
guide (L)
Outer diameter
75 mm – 165 mm
No. 9
No. 131
330852
NOTE
Please refer to the cut off guide user’s manual for details
on how to use it correctly.
SELECTION OF BLADES
To ensure maximum operating effi ciency and results, it is
very important to select the appropriate blade best suited
to the type and thickness of the material to be cut.
NOTE
○ Dimensions of the workpiece mentioned in the table
represent the dimensions when the mounting position of
the base is set nearest to the body of the reciprocating
saw. Caution must be exercised since dimensions of the
workpiece will become smaller if the base is mounted
far away from the body of the reciprocating saw.
1. Selection of HCS blades
The blade number of HCS blades in Table 1 is engraved
in the vicinity of the mounting position of each blade.
Select appropriate blades by referring to Table 1 and 4
below.
Table 1: HCS blades
Blade
No.
Uses
Thickness
(mm)
No. 1
For cutting steel pipe less than 105
mm in diameter
2.5 – 6
No. 2
For cutting steel pipe less than 30
mm in diameter
2.5 – 6
No. 3
For cutting steel pipe less than 30
mm in diameter
Below 3.5
Blade
No.
Uses
Thickness
(mm)
No. 4 For cutting and roughing lumber 50 – 70
No. 5 For cutting and roughing lumber Below 30
No. 8
For cutting vinyl chloride pipe less
than 135 mm in diameter
2.5 – 15
For cutting and roughing lumber Below 105
No. 9
For cutting mild steel pipe less than
130 mm in diameter when used
with cut off guide
2.5 – 6
No. 95
For cutting stainless steel pipe less
than 105 mm in diameter
Below 2.5
No. 96
For cutting stainless steel pipe less
than 30 mm in diameter
Below 2.5
NOTE
No. 1 – No. 96 HCS blades are sold separately as optional
accessories.
2. Selection of BI-METAL blades
The BI-METAL blade numbers in Table 2 are described
on the packages of special accessories. Select
appropriate blades by referring to Table 2 and 4 below.
Table 2: Bl-METAL blades
Blade
No.
Uses
Thickness
(mm)
No. 101
For cutting steel and stainless pipes
less than 60 mm in outer diameter
2.5 – 6
No. 102
For cutting steel and stainless pipes
less than 130 mm in outer diameter
2.5 – 6
No. 103
For cutting steel and stainless pipes
less than 60 mm in outer diameter
2.5 – 6
No. 104
For cutting steel and stainless pipes
less than 130 mm in outer diameter
2.5 – 6
No. 105
For cutting steel and stainless pipes
less than 60 mm in outer diameter
2.5 – 6
No. 106
For cutting steel and stainless pipes
less than 130 mm in outer diameter
2.5 – 6
No. 107
For cutting steel and stainless pipes
less than 60 mm in outer diameter
Below 3.5
No. 108
For cutting steel and stainless pipes
less than 130 mm in outer diameter
Below 3.5
No. 121 For cutting and roughing lumber 300
No. 131 All purposes —
No. 132 All purposes —
NOTE
Nos. 101 – No. 132 Bl-METAL blades are sold separately as
optional accessories.
Table 3: Curved blade
Blade
No.
Uses
Thickness
(mm)
No. 341
For cutting steel and stainless pipes
less than 60 mm in outer diameter
2.5 – 6
