Parts No. I.D. Description Size QTY Parts No. I.D. Description Size QTY
726360 04Q4 STICKER 1 726616 0KQX NUT M6*1.0 T=6 2
327326 08JA SPRING 1 726617 0KQY NUT CHUCK M8*1.25 T=8 1
327327 0A98 COMPRESSION SPRING 1 326453 0KTH STRAIN RELIEF 1
327328 0AM3 WASHER 1 325733 0KUX TERMINAL 1
327329 0AMW SET PLATE 2 327372 0L71 POWER CABLE 1
327330 0AMX CLAMP BOLSTER 1 327373 0LSR CIRCUIT BREAKER SWITCH 1
327331 0C0R CLAMP BOLSTER 1 327374 0LYN STEEL BALL φ10 1
327332 0C10 BLADE 1 327375 0QD5 BRUSH ASS’Y 2
327333 0C12 BLADE 1 327376 0QD7 BRUSH COVER 2
327334 0C15 BEARING SEAT 4 327377 0U7V
CR. RE. TRUSS HD. TAPPING SCREW
M4*16-16 1
327335 0C1N BEARING PROTECTOR 1 327378 0U7W HEX SOC. HD. CAP SCREW M5*0.8-16 1
327336 0CDD FOOT PAD 4 327379 0ZW4 MOTOR 1
327337 0DDW UPPER ARM ROCKER ASS’Y 1 327380 0ZW9 BRACKET-TILT 1
327338 0DE5 HEX SOC. TRUSS HD. SCREW M6*1.0 2 327381 0ZWA TRUNNION BRACKET 1
327339 0DF1 CONTROLLER ASS’Y 1 327382 0ZWG BEARING SEAT ASS’Y 1
327340 0DF6 BELLOWS 1 327383 0ZWH BEARING SEAT 1
327341 0DF8 PLUG HOUSING 1 327384 0ZWJ BUSH 2
327342 0EQK BLADE HOLDER 1 327385 0ZWK POINTER 1
327343 0ES8 PVC HOSE 1 327386 0ZWL HOUSING 1
327344 0FPN EXTENSION SPRING 1 327387 0ZWV SPACER 1
327345 0G1U DUST SHIELD 4 327388 0ZWW LINGAGE BAR 1
327346 0GXP CLAMP-CORD 4 327389 0ZWX BOTTOM ARM ROCKER 1
327347 0GXQ PLUNGER HOUSING 1 327390 0ZX1 CONNECTOR BOX 1
327348 0GXR SHAFT-PIVOT 1 327391 0ZX3 CONNECTOR BOX COVER 1
327349 0HFU SPACER 1 327393 10QX ECCENTRIC ASS’Y 1
327350 0HVE BALL BEARING 1 327394 10RW ECCENTRIC 1
327351 0HY0 SPHERICAL BEARING 1 327395 10RX SPONGE 1
726472 0J3M HEX WRENCH 1 327396 10RZ FLAT WASHER φ8*28-2.5 1
326838 0J4U FLAT WASHER φ6*18-1.5 7 327397 20P1 CLAMP PLATE 1
327352 0J66 FLAT WASHER φ4*10-1 1 327398 20XY HEX SOC. HD. CAP SCREW M6*1.0-20 2
327353 0J91 SPRING WASHER φ4 6 327399 22VH HOUSING RIGHT 1
726501 0JAE EXTERNAL TOOTH LOCK WASHER φ4 1 327400 27Y7 LEAD WIRE ASS’Y 1
726502 0JAF EXTERNAL TOOTH LOCK WASHER φ5 1 327401 2AN6 SWITCH BOX COVER 1
726503 0JAZ WAVE WASHER WW-6 1 327402 2AN8 TABLE 1
327354 0JB0 WAVE WASHER WW-8 2 327403 2AN9 SWITCH BOX 1
0JCW PARALLEL PIN 1 327404 2AYB BASE 1
726526 0JPG HEX HD. BOLT M6*1.0-30 5 327410 2BY8 ROCKET SWITCH 2
327355 0JU4 HEX SOC. HD. CAP BOLT M4*0.7-10 2 327414 2L99 SUPPORT ROD 1
327356 0JU6 HEX SOC. HD. CAP BOLT M4*0.7-16 2 2LBE LABEL 1
327357 0JUZ HEX SOC. HD. CAP BOLT M8*1.25-40 1 327415 2LBG INSERT 1
327358 0JVD HEX SOC. HD. CAP BOLT M5*0.8-35 1 327416 2LBH TENSION HANDLE 1
726534 0JX7 HEX SOC. SET SCREW M6*1.0-6 4 327417 2LBJ PLUNGER HANDLE 1
327359 0JXR HEX SOC. SET SCREW M8*1.25-8 2 327418 2LBR GUIDE CLAMP 1
327360 0K23 HEX SOC. HD.CAP SCREW M6*1.0-16 2 327419 2LBS PUSH BUTTON 1
726539 0K2B HEX SOC. HD.CAP SCREW M6*1.0-16 3 327420 2LBT INDICATED BUTTON 1
326844 0K56 CR. RE. COUNT HD. SCREW M5*0.8-12 2 327421 2LBU AIR DUCT ASS’Y 1
327361 0K70 CR. RE. TRUSS HD. SCREW M4*0.7-16 1 327422 2LBV PLATE COVER 1
726552 0K71 CR. RE. TRUSS HD. SCREW M5*0.8-8 2 327423 2LBW BOLT CLAMP 2
726556 0K7G
CR. RE. ROUND WASHER HD. SCREW
M5*0.8-12 1 327424 2LBX LINGAGE BAR ASS’Y 1
327362 0K9X DRIVE SCREW φ2.3-5 2 327425 2LBY HOLDER BLADE ASS’Y 1
327363 0KA9 CR. RE. PAN HD. TAPPING SCREW M3*24-10 2 327426 2LBZ HOLDER BLADE ASS’Y 1
327364 0KBC CR. RE. PAN HD. TAPPING SCREW M5*16-25 2 327427 2LC1 PLUNGER HOUSING 1
327365 0KBD CR. RE. PAN HD. TAPPING SCREW M4*18-25 4 327428 2LCP BLADE BOX 1
327366 0KCG CR. RE. TRUSS HD. TAPPING SCREW M4*16-8 3 327429 2LFT BOLT CLAMP 1
327367 0KD7 CR. RE. PAN HD. SCREW M4*0.7-10 1 2LK4 TRADE-MARK LABEL 1
327368 0KDK CR. RE. PAN HD. SCREW M5*0.8-16 3 2LK5 LABEL 1
326846 0KDM CR. RE. PAN HD. SCREW M5*0.8-20 3 2LK6 TRADE-MARK LABEL 1
726581 0KDR CR. RE. PAN HD. SCREW M5*0.8-10 6 2LKR CAUTION LABEL 1
327369 0KEE CR. RE. PAN HD. SCREW M5*0.8-50 4 2LKS TILTING SCALE 1
327370 0KKJ
CR. RE. PAN HD. ROUND NECK SCREW
M4*0.7-12 2 2LLF LAMP ASS’Y 1
327371 0KMQ HEX NUT M4*0.7 T=3.2 2 2LQ3 INSTRUCTION MANUAL 1
726615 0KQW NUT CHUCK M5*0.8 T=5 1
PARTS LIST
16” SCROLL SAW MODEL NO. CW 40
PARTS LIST FOR SCHEMATIC Always order by I.D. Number
