1. Cordless Driver Drill
䡬
Battery
<BSL1415> <BSL1815>
(For DS14DSFL) (For DS18DSFL)
FUNCTIONAL DESCRIPTION
NOTE:
The information contained in this Instruction Manual is designed to assist you in the safe operation and
maintenance of the power tool.
NEVER operate, or attempt any maintenance on the tool unless you have first read and understood all safety
instructions contained in this manual.
Some illustrations in this Instruction Manual may show details or attachments that differ from those on your
own power tool.
NAME OF PARTS
Fig. 1
L
Indication
Clutch Dial
Keyless Chuck
Shift Knob
Handle
Push Button
Housing
Switch Trigger
Battery
Ventilation holes
Latch
Ventilation holes
Terminals
Battery cover
Latch
Terminals
Battery cover
Hook
Nameplate
R
Indication
