English
18
HOW TO SELECT TIGHTENING TORQUE
Table 6
Clutch dial
Tightening torque Operation example
position
Approximately 9 in.-lbs. (10 kg-cm)
Approximately 15 in.-lbs. (17 kg-cm)
Approximately 23 in.-lbs. (26 kg-cm)
Approximately 35 in.-lbs. (40 kg-cm)
Approximately 43 in.-lbs. (49 kg-cm)
Approximately 52 in.-lbs. (60 kg-cm)
High speed: approximately 71 in.-lbs.
(82 kg-cm) (DS14DSFL)
approximately 106 in.-lbs.
(122 kg-cm) (DS18DSFL)
Low speed: approximately 302 in.-lbs.
(347 kg-cm) (DS14DSFL)
approximately 400 in.-lbs.
(459 kg-cm) (DS18DSFL)
Machine screw
tightening Screw
tightening for soft wood
material
Screw tightening for
hard wood material
Thick screw tightening
When used as a drill.
1
3
7
13
17
22
NOTE:
The selected content shown in Table 4 indicates
the differences according to screw type, screw size
and material used.
CAUTION:
●
While operating the Cordless driver drill, take care
not to lock the motor.
If the motor is locked, immediately turn the power
off.
If the motor is locked for a while, the motor or
battery will be burnt.
●
Do not tighten too strongly as the screw heads
will be damaged.
THE SCOPE AND SUGGESTIONS FOR USES
Table 5
Work Clutch dial position Suggestions
Wood
Drilling Steel Use for drilling purpose.
Aluminum
Machine
1 – 22
Use the bit and socket matching the
Screw
screw screw diameter.
tightening
Wood
1 –
Use after drilling a pilot hole.
screw
01Eng_DS14DSFL_US 6/8/10, 6:25 PM18
