THE SCOPE AND SUGGESTIONS FOR USES
Table 6
HOW TO SELECT TIGHTENING TORQUE
Table 7
Work Cap position Suggestions
Wood
Drilling Steel Use for drilling purpose.
Aluminum
Screw
Small
1 – 22
Use the bit and socket matching the screw
tightening
screw diameter.
Wood
1 –
Use after drilling a pilot hole.
screw
Machine screw
tightening.
Screw tightening for
soft wood material.
Thick screw tightening.
When used as a drill.
Screw tightening for
hard wood material.
Cap
Tightening torque Operation example
position
1 Approximately 18 in-lbs. (20 kg-cm)
4 Approximately 27 in-lbs. (31 kg-cm)
7 Approximately 37 in-lbs. (43 kg-cm)
10 Approximately 47 in-lbs. (54 kg-cm)
16 Approximately 67 in-lbs. (77 kg-cm)
22 Approximately 87 in-lbs. (100 kg-cm)
High speed: Approximately 106 in-lbs.
(122 kg-cm)(DS14DMR)
Approximately 124 in-lbs.
(143 kg-cm)(DS18DMR)
Low speed: Approximately 450 in-lbs.
(550 kg-cm)(DS14DMR)
Approximately 560 in-lbs.
(633 kg-cm)(DS18DMR)
