English - 8 -

LCD TV and Operating Buttons

FRONT VIEW

REAR VIEW

TV/AV

P\CH

Standby button1.

TV/AV button2.

Programme Up/Down 3.

buttons

Volume Up/Down buttons4.

Note: Press “ ”/“ ”

buttons at the same time to view

main menu.

[GB]_MB25_UKIDTV_BRONZE6_19856W_1055UK_10062536_50145791.indd 8[GB]_MB25_UKIDTV_BRONZE6_19856W_1055UK_10062536_50145791.indd 8 05.06.2009 15:24:3505.06.2009 15:24:35
