Hitachi LS Series User Manual

- 2 -
Machine type Electric chain hoist L-series
Power supply
L-type, LN-type (3phase) : 220V / 380 - 415V 50Hz, 346V 50Hz, 220 - 230 / 440 - 460V 60Hz
LS-type (1phase) : 200 - 220V 50Hz, 220 - 240V 50Hz, 110V 60Hz, 220V 60Hz
L-type
(single speed)
500kg 0.63kW (50Hz), 0.75kW (60Hz)
250kg 0.45kW (50Hz), 0.55kW (60Hz)
150kg 0.38kW (50Hz), 0.45kW (60Hz)
LN-type
(dual speed)
500kg 0.63 / 0.16kW (50Hz), 0.75 / 0.19kW(60Hz)
250kg 0.45 / 0.11kW (50Hz), 0.55 / 0.14kW (60Hz)
150kg 0.38 / 0.10kW (50Hz), 0.45 / 0.11kW (60Hz)
LS-type
(single phase)
500kg 0.30kW (50Hz), 0.35kW (60Hz)
250kg 0.25kW
Operating voltage AC24V
Electric power feeding method Cabtire cable power supply
Protection structure IP54
Chain (mm)
6.3 (diameter) × 19.1 (pitch)
Environment
Ambient
Temperature
-10ºC ~ 40ºC (no freezing)
Humidity 90% or less (no condensation)
Classification ISO : M4, FEM : 1Am
Noise level 75dB or less (A scale : measured at 1m away from the hoist)
Color Orange (Munsell : 2.5YR 6/12)
•
In the special circumstances shown below, the standard specifications cannot be used, so please contact us
separately.
1. When using in acidic, alkaline, salty or in corrosive gas environments.
2. When the ambient temperature exceeds 40°C or the humidity exceeds 90%.
3. When using in an organic solvent or an explosive dust environment, which has danger of explosion or
flammability.
2. Product specifications
2-1. Standard specification
Machine type
Intermittent periodic rating (at 63% load factor)
Duty factor Start frequency
L-type (single speed) 40% ED 240starts/h
LN-type
(dual speed)
High-speed 20% ED 60starts/h
Low-speed 10% ED 120starts/h
LS-type
(single speed, single phase)
25% ED 150starts/h
2-2. Rated specification

Hitachi LS Series Specifications

General

Brand	Hitachi
Model	LS Series
Category	Chain Hoists
Language	English
