English
16
WARNING
WARNING
ADJUSTING AIR PRESSURE
● Do not exceed 120 psi
(8.3 bar 8.5 kgf/cm
2
).
Adjust the air pressure at recommended operating pressure 70 – 120 psi (4.9 – 8.3 bar 5 –
8.5 kgf/cm
2
) according to the length of nails and the hardness of workpiece.
The correct air pressure is the lowest pressure which will do the job. Using the Nailer at a
higher than required air pressure unnecessarily over stresses the Nailer.
LOADING NAILS
● When loading nails into Nailer,
1) do not pull trigger;
2) do not depress push lever; and
3) keep Nailer pointed downward.
(1) Pull the nail feeder back.
(2) Pull the nail feeder until the concave portion of the magazine cover clicks.
Nail Feeder
Concave portion
Nail Feeder
Magazine Cover
To Next Page
