– 19 –
English
Parts No. I.D. Description Size QTY Parts No. I.D. Description Size QTY
726324 0870 EXTENTION WING ASS’Y 2 726529 0JQ1 HEX. HD. BOLT M10*1.5-45 4
726325 0874 ROLLING WHEEL 2 726530 0JUB HEX. SOC. HD. CAP BOLT M5*0.8-12 1
726326 0875 SHAFT SLEEVE 8 726531 0JV0 HEX. SOC. HD. CAP BOLT M8*1.25-45 1
726327 0876 SHAFT 2 726536 0JXQ HEX. SOC. SET SCREW M10*1.5-12 1
726328 0877 SPRING PLATE 2 326666 0JZ4 HEX. SOC. SET SCREW M6*1.0-8 2
726329 0878 BODY 1 726528 0JZN ARBOR BOLT M8*1.25-20 1
726330 0879 NEEDLE POINTER 1 326667 0JZY HEX. SOC. TRUSS HD. SCREW M6*1.0-12 2
726331 0880 ADJUST SCREW 4 726537 0K1D HEX. HD. SCREW AND WASHER M6*1.0-16 16
726332 0881 BEARING SEAT 1 726539 0K2B HEX SOC. HD. CAP SCREW M6*1.0-16 2
726333 0882 PULLEY 1 726541 0K30 HEX. SOC. TRUSS HEAD & WASHER ASSEMBLIED M6*1.0-16 8
726334 0886 TABLE INSERT 1 726542 0K33 CR. RE. PAN HD. SCREW & WASHER M4*0.7-8 2
726335 0887 SPROCKET 3 726544 0K3H CR. RE. PAN HD. SCREW & WASHER M6*1.0-12 20
726336 0888 SHAFT SLEEVE 1 726546 0K47 CR. RE. PAN HD. SCREW & WASHER M6*1.0-20 1
726337 0889 ANCHOR BLOCK 4 726550 0K5B CR. RE. COUNT HD. SCREW M6*1.0-12 14
726338 0893 FOLLOWER PLATE 1 726551 0K61 CR. RE. COUNT HD. SCREW M5*0.8-12 2
726390 086G INSERT 1 726552 0K71 CR. RE. TRUSS HD. SCREW M5*0.8-8 8
726391 086H CHAIN 1 726555 0K7F CR. RE. ROUND WASHER HD. SCREW M5*0.8-8 2
726392 086K SPROCKET 2 726557 0K7K CR. RE. ROUND WASHER HD. SCREW M6*1.0-12 23
726393 086L BEARING COVER 2 726560 0K84 CR. RE. COUNT HD. TAPPING SCREW M4*0.7-12 3
726394 086N GUIDE PLATE 2 726563 0K91 CR. RE. TRUSS HD. TAPPING SCREW M4*16-12 2
726395 086P TABE PLATE 1 726573 0KB9 CR. RE. PAN HD. TAPPING SCREW M5*16-10 4
726396 086S SCREW BAR 2 726584 0KE9 CR. RE. PAN HD. SCREW M6*1.0-30 2
726397 086T SUPPORT 4 726593 0KKL CR. RE. PAN HD. ROUND NECK SCREW M6*1.0-16 1
726398 087A SPRING 1 726597 0KMS HEX. NUT M6*1.0 T=5 4
726399 087B RIVET 1 726603 0KMY HEX. NUT M8*1.25 T=6.5 1
726400 087G ARM BRACKET 1 726613 0KQM SQUARE NUT M6*1.0 T=5 8
726401 087H SPACER 1 726616 0KQX NUT M6*1.0 T=6 4
726402 087K HANDLE 1 726617 0KQY LOCK NUT M8*1.25 T=8 2
726403 087N LINK BAR 2 726619 0KRJ U-TYPE NUT M4*0.7 2
726404 087Q SLEEVE 2 726636 0LXZ DSICCANT 2
726405 087S CHAIN 1 726637 0LYR STEEL BALL 1
726406 087T CHAIN 1
326458 0QQU CARBON BRUSH ASS’Y 2
726407 087U BEARING COVER 1
326243 0QR0 BRUSH COVER 2
726408 088A COMPRESSION SPRING 4 726339 2111 CUSHION 2
726409 088B FEED SHAFT 2 726340 2113 SET BOLT 2
726410 088C SHAFT SLEEVE 1 726341 2114 BLADE 2
726411 088D SET PLATE 4 726342 2116 TENSIONH ANDLE 1
726412 088E NUT 2 726343 2118 TENSION HANDLE 1
726413 088F NUT 2 726344 2125 BASE 1
726414 088G ADJUSTABLE NUT 2 726659 210Y COVER 1
726415 088H MITER GUIDE 1 726660 210Z FOLLOWER PLATE 1
726416 088J DUST PORT 1 726661 211C TOOL BOX COVER 1
726417 088L SIDE COVER 1 726662 211D TOOL BOX COVER 1
726418 088N SIDE COVER 1 726663 211E BASE 4
726419 088R COVER 1 726664 212S SPONGE 1
726420 088S SCALE RING 1 726667 216J V-RIBBED BEIT (POIYOURETHANE) 1
726421 089Q SET PLATE 1 726669 21XQ CR. RE. ROUND WASHER HD. SCREW M6*1.0-60 4
726422 089R SET PLATE 1 726670 221Q CUTTER HEAD 1
726423 089S SPROCKET 1 726671 221R PRESSURE BAR 2
726424 089Y ROLLING WHEEL 2 726672 222E NEEDLE POINTER 1
726425 089Z SHAFT 2 726734 24ZN HANDLE 1
726426 08A0 BRACKET TRAY 4 726747 26DP SPECIAL BOLT 4
726427 08A1 MOTOR PULLEY 1 726792 28KA PLATE COVER 1
726428 08A2 SPRING 1 726793 28KB COVER-RINHT 1
726429 08A5 FOUNDATION STONE ASS’Y 2 726794 28KL HANDLE 2
726430 08AK C0LLAR 1 726795 28KP KNOB 1
726431 08AM MOTOR BASE 1 726801 28MA SACLE PLATE ASS’Y 1
726467 0HV4 BALL BEARING 2 726814 28PE HANDLE BAR ASS’Y 1
726468 0HVM BALL BEARING 2 726817 28QS POWER CORD CLAMP 2
726473 0J3P HEX WRENCH 1 726822 28VG TRADE-MARK LABEL 1
726477 0J4E FLAT WASHER φ6*13-1 2 726823 28VH CAUTION LABEL 1
726484 0J6G FLAT WASHER φ8.2*18-2.0 1 726825 28VK STICKER 2
726491 0J78 FLAT WASHER 1/4*1/2-3/32 6 726826 28VL SCALE 1
726492 0J7B FLAT WASHER 5/16*25/32-1/8 2 726830 28VQ WARNING LABEL 1
726497 0J95 SPRING WASHER φ6 2 326542 2GMK MOTOR ASS’Y 1
726504 0JBA WAVE WASHER 1 326641 2HBU WARNING LABEL 1
726511 0JDC SPRING PIN 2 326642 2HBY SCALE 1
726512 0JEC C-RING 1 326643 2HC2 BRACKET-TILT 1
726514 0JEV E-RING 4 326644 2HC5 SCALE 1
726518 0JGB PARALLEL KEY 1 326649 2HGQ MIDDLE BASE 1
726524 0JPC HEX. HD. BOLT M6*1.0-12 1 326650 2HR6 KICK BACK PAWL ASS’Y 1
726525 0JPF HEX. HD. BOLT M6*1.0-25 4
13” (330mm) PLANER MODEL NO. P13F
PARTS LIST FOR SCHEMATIC Always order by I.D. Number
PARTS LIST
