Hitachi RAS-2WHVRP User Manual


Split system - Indoor unit
YUTAKI S
Model Power supply Operation mode
Max.
current
(A)
Power supply
cables
Transmitting
cables
Actuator
cables
EN60335-1 EN60335-1 EN60335-1
RWM-(2.0-3.0)NRE(-W) 1~ 230V 50Hz
Without electric heaters 0.2 2 x 0.75 mm² + GND
2 x 0.75 mm
2
(Shielded
cable)
2 x 0.75
mm
2
+ GND
With electric heater 14.6 2 x 2.5 mm² + GND
With DHW tank heater 14.6 2 x 2.5 mm² + GND
With electric and DHW tank heaters 28.9 2 x 6.0 mm² + GND
RWM-(4.0-6.0)NE(-W)
1~ 230V 50Hz
Without electric heaters 0.3 2 x 0.75 mm² + GND
With electric heater 29.0 2 x 6.0 mm² + GND
With DHW tank heater 14.7 2 x 2.5 mm² + GND
With electric and DHW tank heaters 43.4 2 x 10.0 mm² + GND
3N~ 400V 50Hz
Without electric heaters 0.3 4 x 0.75mm² + GND
With electric heater 9.9 4 x 2.5 mm² + GND
With DHW tank heater 14.7 4 x 2.5 mm² + GND
With electric and DHW tank heaters 24.2 4 x 6.0 mm² + GND
RWM-(8.0/10.0)NE(-W) 3N~ 400V 50Hz
Without electric heaters 0.6 4 x 0.75 mm² + GND
With electric heater 14.9 4 x 4.0 mm² + GND
With DHW tank heater 15.0 4 x 2.5 mm² + GND
With electric and DHW tank heaters 29.2 4 x 6.0 mm² + GND
? NOTE
The data corresponding to DHW tank heater is calculated in combination with the domestic hot water tank accessory “DHWT-(200/300)S-3.0H2E”.
YUTAKI S COMBI
Model Power supply Operation mode
Max.
current
(A)
Power supply
cables
Transmitting
cables
Actuator
cables
EN60335-1 EN60335-1 EN60335-1
RWD-(2.0-3.0)
NRW(S)E-(200/260)(-K)
(-W)
1~230V 50Hz
Without electric heaters 0.2 2 x 0.75 mm² + GND
2 x 0.75 mm
2
(Shielded
cable)
2 x 0.75 mm
2
+ GND
With electric heater 14.6 2 x 2.5 mm² + GND
With DHW tank heater 12.7 2 x 2.5 mm² + GND
With electric and DHW tank heaters 27.1 2 x 6.0 mm² + GND
RWD-(4.0-6.0)
NW(S)E-(200/260)S(-K)
(-W)
1~230V 50Hz
Without electric heaters 0.3 2 x 0.75 mm² + GND
With electric heater 29.0 2 x 6.0 mm² + GND
With DHW tank heater 12.8 2 x 2.5 mm² + GND
With electric and DHW tank heaters 41.5 2 x 10.0 mm² + GND
3N~400V 50Hz
Without electric heaters 0.3 4 x 0.75 mm² + GND
With electric heater 9.9 4 x 2.5 mm² + GND
With DHW tank heater 12.8 4 x 2.5 mm² + GND
With electric and DHW tank heaters 22.4 4 x 6.0 mm² + GND
ELECTRICAL AND CONTROL SETTINGS
PMML0510 rev.1 - 10/2019
