Pull the support rod out of its clip
and insert the end into the hole in
the hood.
Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower left corner of the dashboard.
The hood will pop up slightly.
Lift it up slightly to remove the
support rod from the hole. Put the
support rod back into its holding clip.
Lower the hood to about a foot
(30cm)abovethefender,thenletit
drop. Make sure it is securely
latched.
If the hood latch handle moves
stiffly, or if you can open the hood
without lifting the handle, the
mechanism should be cleaned and
lubricated.
Put your fingers under the front
edge of the hood near the center.
The hood latch handle is above
the ‘‘H’’ logo. Push this handle up
to release it. Lift up the hood.
1. 2.
3.
To Close the Hood:
Opening and Closing the Hood
Service Station Procedures
142
LATCH
HOOD RELEASE HANDLE SUPPORT ROD
CLIP
０７／０４／２６ １８：５４：４８ ３１ＳＣＶ６５０ ０１４７
