Make sure there are no objects
near the anchors that could
prevent a secure connection
between the child seat and the
anchors.
To install a LATCH-compatible child
seat:
Place the child seat on the vehicle
seat, then attach the seat to the
lower anchors according to the
child seat maker’s instructions.Remove both anchor covers by
pulling forward.
Some LATCH-compatible seats
have a rigid-type connector as
shown above.
The lower anchors are located
between the seat-back and seat
bottom, and are to be used only with
a child seat designed for use with
LATCH.
The location of each lower anchor is
indicated by a small button above the
anchor point.
Your vehicle is equipped with
LATCH (lower anchors and tethers
for children) at the rear seats.
1.
2.
3.
Installing a Child Seat with
LATCH
Installing a Child Seat
46
MARKS
Rigid-type
LOWER ANCHORS
ANCHOR COVER
