Technical Data
Cordless hedge trimmer
HHH36AXB
Blade type roughing
No-load stroke rate min
-1
3000
Cutting length mm 600
Tooth opening mm 28
Tooth pitch mm 35
Handle Rotation ° +90/0/-90
Sharpening Angle ° 45
Weight (without batteries) according
to EPTA-Procedure 01:2014
kg 5.0
Serial number See serial number (type plate) on the machine
Only LI-Ion batteries DP3640XA, DP3660XA, DPW3660XA, DPW3690XA and battery charger CV3680XA can be used
with this machine.
Noise/Vibration Information
Sound emission values
determined according
to EN 60745-2-15
Typically the A-weighted
noise levels of the product
are:
Sound pressure level dB(A) 80
Sound power level dB(A) 101
Uncertainty K dB =1.91
Wear hearing protection!
Vibration total values ah
(triax vector sum) and
uncertainty K determined
according
to EN 60745-2-15:
Vibration emission value a
h
Uncertainty K
m/s
2
m/s
2
1.9
=1.5
The vibration level given in this information sheet has
been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool
with another. It may be used for a preliminary assessment
of exposure.
The declared vibration emission level represents the
main applications of the tool. However if the tool is used
for different applications, with different accessories
or insertion tools or is poorly maintained, the vibration
emission may differ. This may significantly increase the
exposure level over the total working period.
An estimation of the level of exposure to vibration
should also take into account the times when the tool is
switched off or when it is running but not actually doing
the job. This may significantly reduce the exposure level
over the total working period.
Identify additional safety measures to protect the
operator from the effects of vibration such as: maintain
the tool and the accessories, keep the hands warm,
organisation of work patterns.
Mounting and Operation
The numbering of the figures refer to the illustrations of
the machine on the graphics page.
Action Figure Page
Delivery Scope
1
83
Inserting the Battery
2
83
Removing the Battery
3
83
Switching On and Off
4
84
Working Advice
5
84
Handle Rotation
6
84
Lubrication
7
85
Selecting Accessories
8
85
Working Advice
When cutting hedges always start with the sides first,
working from the bottom upwards in a radial movement
followed by the top. If hedge is deep, ensure cutting is
carried out in stages.
Never attempt to remove material from the blades while
the battery is inserted and do not hold material to be
cut. Switch off and remove the battery from the machine
whenever clearing jammed material. Failure to do so may
result in serious personal injury.
Take extra care when cutting above shoulder height.
Caution! Base plate may become hot during operation.
Wait until the blades have come to a standstill before
placing down the hedge trimmer.
Your machine is fitted with an electronic device, which will
minimise the risk of the blade jamming in heavy cutting
conditions. This will allow easy removal of the machine
from the hedge. Restart the machine by the on/off switch.
