427
uuWhen DrivinguAdjusting Headlight Distribution
Adjusting Headlight Distribution
Driving the right-hand type vehicle in right-hand traffic, or the left-hand type vehicle
in left-hand traffic causes headlight glare to oncoming vehicles. You need to alter
the headlight beam distribution using masking tape.
1. Prepare for two rectangular pieces of masking tape, measuring 40 mm
(1.57 inches) wide and 100 mm (3.15 inches)
*2
or 80 mm (3.94 inches)
*1
long.
u Use masking tape that can shut out light, such as seal type waterproof vinyl.
2. Affix the tape to the lens as shown.
*1: For the driver's side headlight
*2: For the passenger’s side headlight
1Adjusting Headlight Distribution
Be careful not to adhere the tape to an incorrect
location. If the headlight beam is distributed
incorrectly, it may not comply with your country’s
legal requirements. Ask your dealer for details.
a Centre point f 10 mm (0.39 inches)
b 40 mm (1.57 inches) g 52 mm (2.05 inches)
c 48 mm (1.89 inches) h 48 mm (1.89 inches)
d 32 mm (1.26 inches) i 40 mm (1.57 inches)
e 10 mm (0.39 inches)
23 CIVIC TYPE R JSS (KE KG)-32T406000_01.book 427 ページ ２０２２年７月１１日 月曜日 午前７時２０分
To Next Page
