Honda CRF250L/LA Rally 2020 User Manual

Seat
#
Removal
1. Remove the hook bolts and collars.
2. Pull the seat back and up.
#
Installation
1. Align the recess with the tab and insert
the prongs into the front stay and rear
stays.
2. Install the collars onto the hook bolts.
Tighten the hook bolts.
Torque: 15 lbf·ft (21 N·m, 2.1 kgf·m)
Removing & Installing Body Components u Seat
Maintenance
56
Hook bolt
Prongs
Hook bolt
Collar
Tab
Recess
Front stay
Seat
Rear stays
Collar
