Honda CRF250R 2018 User Manual

36 Servicing Your Honda
Fuel Tank
6. Slide the shroud (10) toward the down so that
the shroud tab (11) and the slot (12) on the air
cleaner housing cover (13) is aligned.
7. Install the shroud C bolt (14), B bolt (15) and
shroud A bolt (16).
Tighten the shroud A and B bolts to the
specified torque:
7 lbf·ft (10 N·m, 1.0 kgf·m)
Tighten the shroud C bolt to the specified
torque:
3.8 lbf·ft (5.2 N·m, 0.5 kgf·m)
The right and left shrouds can be installed in
the same manner.
8. Install the seat (page 33).
(10) shroud (14) shroud C bolt
(11) shroud tab (15) shroud B bolt
(12) slot (16) shroud A bolt
(13) air cleaner housing cover
(10)
(14)
(15)
(16)
(13)
(11)
(12)

Honda CRF250R 2018 Specifications

General

Bore x Stroke	79.0mm x 50.9mm
Compression Ratio	13.9:1
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability; 12.4 inches travel
Front Brake	Single 260mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Wheelbase	58.3 inches
Seat Height	37.8 inches
Induction	Programmed Fuel Injection (PGM-FI)
Transmission	5-speed
Final Drive	Chain
Front Tire	80/100-21
Rear Tire	100/90-19
Trail	4.6 inches
