Honda CRF250R 2018 User Manual

Fuel System
(cont’d)
Servicing Your Honda 45
Empty the fuel tank into an approved gasoline
container using a commercially available hand
siphon or an equivalent method.
Be careful not to damage the fuel pump while
draining the fuel in the fuel tank.
Removal
1. Relieve the fuel pressure (page 42).
2. Disconnect the fuel line from the fuel pump
(page 42).
3. Remove the fuel tank (1) by releasing the
stopper cable (2) from the frame hook (3) of
the frame.
4. Pull the harness band clip (4) while pressing
both side of the anchor and disconnect it.
5. Remove the fuel pump mounting nuts (5), fuel
pump mounting cap nut (6), stopper cable
guide (7), stopper cable (2), washer (8), collars
(9), conical spring washers (10) and fuel pump
plate (11) while holding the fuel tank.
Fuel Pump Filter Replacement
WARNING
Gasoline is highly flammable and
explosive. You can be burned or seriously
injured when handling fuel.
• Stop the engine and keep heat, sparks
and flame away.
• Handle fuel only outdoors.
• Wipe up spills immediately.
(1) fuel tank (3) frame hook
(2) stopper cable (4) harness band clip
(2)
(3)
(1)
(4)
(2) stopper cable
(5) fuel pump mounting nuts
(6) fuel pump mounting cap nut
(7) stopper cable guide
(8) washer
(9) collars
(10) conical spring washers
(11) fuel pump plate
(6)
(5)
(2)
(7)
(8)
(9)
(10)
(11)

Honda CRF250R 2018 Specifications

General

Bore x Stroke	79.0mm x 50.9mm
Compression Ratio	13.9:1
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability; 12.4 inches travel
Front Brake	Single 260mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Wheelbase	58.3 inches
Seat Height	37.8 inches
Induction	Programmed Fuel Injection (PGM-FI)
Transmission	5-speed
Final Drive	Chain
Front Tire	80/100-21
Rear Tire	100/90-19
Trail	4.6 inches
