Honda CRF250R 2020 User Manual

122 Servicing Your Honda
Battery
Installation
1. Reinstall the battery (1) in the reverse order of
removal. Be sure to connect the positive (+)
terminal (2) first, then the negative (–) terminal
(3).
2. Tighten the positive (+) and negative (–)
terminal bolts (4) to the specified torque:
1.5 lbf·ft (2.0 N·m, 0.2 kgf·m)
3. Install the battery band (5).
Be sure to read the information that came with
your battery charger and follow the instructions on
the battery. Improper charging may damage the
battery.
We recommend using a charger recommended by
your lithium-ion (li-ion) battery manufacturer
which can be purchased from your dealer. These
units can be left connected for long periods without
risking damage to the battery. However, the
lithium-ion (li-ion) battery may degrade if stored
with a charger connected. Do not intentionally
leave the charger connected longer than the time
period recommended in the charger’s instructions.
Using a battery charger that is not recommended
can cause permanent damage to your battery.
(1) battery (4) terminal bolts
(2) positive (+) terminal
(5) battery band
(3) negative (–) terminal
(1)
(3) (4)
(2)
(5)
Battery Charging

Honda CRF250R 2020 Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	79.0mm x 50.9mm
Compression Ratio	13.9:1
Ignition	Full transistorized ignition
Front Brake	Single 260mm disc with twin-piston caliper
Front Tire	80/100-21
Rear Tire	100/90-19
Trail	4.6 inches
Wheelbase	58.3 inches
Seat Height	37.8 inches
Fuel Capacity	1.6 gallons
Ground Clearance	13.2 inches
Valve Train	Unicam, 4-valve
Induction	Programmed Fuel Injection (PGM-FI)
Transmission	5-speed
Final Drive	#520 chain
Front Suspension	49mm inverted Showa coil-spring fork with rebound and compression damping adjustability; 12.2 inches travel
Rear Suspension	Showa® Pro-Link® system with rebound and compression damping adjustability; 12.4 inches travel
Rear Brake	Single 240mm disc
Rake	27.2°
