Honda CRF250R 2020 User Manual

50 Servicing Your Honda
Fuel System
Make sure the fuel remains enough (0.3 US gal
(1.0 Ɛ) minimum) in the fuel tank and add fuel if
necessary before increasing fuel pressure.
With the throttle closed.
Pull the clutch lever all the way in, and depress the
start button.
The engine will start up by increasing the fuel
pressure.
If the engine does not start, check all connector
connections and/or refer to an official Honda
Service Manual (page 166) for troubleshooting of
the PGM-FI symptom.
Fuel Pressure Increasing

Honda CRF250R 2020 Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	79.0mm x 50.9mm
Compression Ratio	13.9:1
Ignition	Full transistorized ignition
Front Brake	Single 260mm disc with twin-piston caliper
Front Tire	80/100-21
Rear Tire	100/90-19
Trail	4.6 inches
Wheelbase	58.3 inches
Seat Height	37.8 inches
Fuel Capacity	1.6 gallons
Ground Clearance	13.2 inches
Valve Train	Unicam, 4-valve
Induction	Programmed Fuel Injection (PGM-FI)
Transmission	5-speed
Final Drive	#520 chain
Front Suspension	49mm inverted Showa coil-spring fork with rebound and compression damping adjustability; 12.2 inches travel
Rear Suspension	Showa® Pro-Link® system with rebound and compression damping adjustability; 12.4 inches travel
Rear Brake	Single 240mm disc
Rake	27.2°
