Honda GCV530 User Manual

＋
−
−
＋
↓
6
BATTERY CONNECTIONS
NEGATIVE ( )
BATTERY CABLE
POSITIVE ( )
BATTERY CABLE
STARTER
SOLENOID
(to engine body)
Connect the battery positive ( ) cable to the starter solenoid
terminal, as shown.
Connect the battery negative ( ) cable to an engine mounting bolt,
frame bolt, or other good engine ground connection.
Check the battery cable connections to be sure the cables are
tightened and free of corrosion. Remove any corrosion, and coat
the terminals and cable ends with grease.
Use a 12 volt battery with an ampere-hour rating of at least 45AH.

Honda GCV530 Specifications

General

Lubrication System	Forced splash
Displacement	530 cc
Ignition System	Transistorized magneto
Fuel System	Carburetor
Air Cleaner	Dual element type
Cooling System	Air-cooled
Starting System	Recoil starter
