9
UPPER LIMIT
LOWER LIMIT
OIL FILLER CAP/
DIPSTICK
OIL FILLER CAP/DIPSTICK
Place the engine horizontally on a level surface.
Remove the oil filler cap/dipstick and wipe it clean.
Fully insert the dipstick without screwing it in, then remove it to
check the oil level.
If the oil level is near or below the lower limit mark on the
dipstick, and fill with the recommended oil to the upper limit
mark.
Reinstall the oil filler cap/dipstick.
1.
2.
3.
4.
5.

Honda GCV530 Specifications

General

Lubrication System	Forced splash
Displacement	530 cc
Ignition System	Transistorized magneto
Fuel System	Carburetor
Air Cleaner	Dual element type
Cooling System	Air-cooled
Starting System	Recoil starter
