TECHNICAL & CONSUMER INFORMATION
62
SPECIFICATIONS
Mower Model
Dimensions, Weights and Capacities
Engine Design and Performance
Transmission Design and Performance
HRB217TDA Honda rotary mower, 21 inch mower deck, 6.5 bhp, three-
speed transmission, zone start, USA market
Length 68.1 in (1730 mm)
Width at Mower Deck 23-1/4 in (590 mm)
Height 39.0 in (990 mm)
Dry Weight 80.5 lb (36.5 kg)
Cutting Width 21 in (530 mm)
Approximate Cutting
Height (adjustable)
3/4 in (19 mm), 1 in (25 mm), 1-1/2 in (38 mm),
2 in (51 mm), 2-1/2 in (64 mm), 3 in (76 mm)
Fuel Tank Capacity 0.29 US gal (1.1 l)
Engine Oil Capacity 0.58 US qt (0.55 l)
Grass Bag Capacity 21.9 US gal (2.4 bushels; 2.9 cu ft; 83 l)
Engine Model GCV190
Engine Type 4-stroke, overhead-camshaft, single-cylinder, forced
air-cooled
Displacement 11.4 cu in (190 cc)
Bore and Stroke 2.71 x 1.97 in (69 x 50 mm)
Compression Ratio 8.5:1
Ignition System Transistorized magneto
Maximum Horsepower 6.5 bhp (4.8 kW) at 3,600 rpm
Maximum Torque 9.74 ft-lb (13.2 N•m) at 2,500 rpm
Transmission Type 3 speed, manual shift
Mower Ground Speed
(with engine at 3,100 rpm)
1st: 1.8 mph (2.9 km/h), 2nd: 2.7 mph (4.3 km/h),
3rd: 3.4 mph (5.4 km/h)
