17
Specifications
Mower Features
Dimensions and Weights
Engine Design and Performance
Transmission Design and Performance
Maintenance
HRR2169VYUA Honda rotary mower, 530mm mower deck,
3-in-1 Clip Director, Smart Drive variable
speed transmission, Roto Stop blade brake,
Auto Choke System
Length 1534mm
Width 582mm
Overall height * 1014mm
Dry weight 41.0kg
Cutting width 530mm
Cutting heights (7) 28 ~ 102mm
Grass bag
capacity
66L
Noise level < 75 dB(A) @ 7.5(m) LpA
* 1-1/4 inch cutting height and handle in highest position
Model GCV160
Type 4-stroke, overhead-cam,
single-cylinder, air-cooled
Displacement
160cm
3
Bore and stroke 64 x 50mm
Compression ratio 8.5:1
Ignition system Transistorized magneto
Type Variable speed
Ground speed 0 ~ 1.8m/s
Fuel Unleaded fuel with a pump
octane rating of 86 or higher containing
no more than 10% ethanol by volume
Capacity: 0.93 litres
See “AVOIDING FUEL-RELATED
PROBLEMS” on page 18
page 7
Blade Bolt
Torque
49 ~ 59N•m page 11
Engine Oil SAE 10W-30, API SJ or later
Capacity: 0.50litres
Refill amount: 0.35 ~ 0.40litres*
page 12
Spark Plug Type: NGK - BPR5ES
Gap: 0.7 ~ 0.8mm
page 13
Idle speed 1,700 +/- 150rpm Shop
manual
Maximum
Governed
Speed
3,100 +0/-150rpm ** Shop
manual
Valve
clearance
(cold)
Intake: 0.15 ± 0.02mm
Exhaust: 0.20 ± 0.02mm
Shop
manual
* Actual amount will vary due to residual oil in the engine. Always
use the dipstick to confirm the actual level (page 6).
** Do not try to increase the engine speed above the maximum
governed speed; the blades could fracture and come apart.
