20
ENGLISH
SPECIFICATIONS
MODEL HRX537C2
TYPE VYEA
DESCRIPTION CODE MAGA
GENERAL
Length
1,621 mm
Handlebar height
(Middle position)
976 mm
Dry weight
43.8 kg
Width
585 mm
Cut width
530 mm
Cut height adjustments
20 mm, 32 mm, 46 mm,
62 mm, 75 mm, 88 mm, 100 mm
Grass bag capacity
88 l
Sound pressure level at
operator’s ears (According
to 2006/42/EC directive)
86 dB(A)
Uncertainty
1 dB(A)
Sound power level
measured (According to
2000/14/EC directive)
97 dB(A)
Uncertainty
1 dB(A)
Sound power level
guaranteed (According to
2000/14/EC directive)
98 dB(A)
Vibration transmitted
(According to 2006/42/EC
directive)
4.5 m/s
2
Uncertainty
2.3 m/s
2
ENGINE
Model
GCV190
Type
4-stroke, single cylinder, vertical shaft, OHC
Displacement
187 cc
Bore and stroke
69 x 50 mm
Cooling
Forced air
Lubrication
Splash and spray
Compression ratio
8.5:1
Maximum speed
2,850 rpm
Idle speed
1,700 ± 150 rpm
Ignition system
Transistorized magneto
Spark plug
NGK: BPR5ES
Spark plug gap
0.7 ~ 0.8 mm
Air cleaner
Dry element type
Recommended fuel
Unleaded petrol with a research
octane rating of 91 or higher
Fuel tank capacity
0.91 l
Recommended oil
SAE 10W-30, API SJ or later
Engine oil capacity
0.55 l
* Refill amount: 0.35 ~ 0.40 l
* Actual amount will vary due to residual oil in the engine. Always use the
dipstick to confirm the actual level (see page 6).
DRIVE
Type
Variable speed transmission, thumb or hand
operation (twist grip)
Engine to transmission
V-belt
Main clutch
Slipping friction cone type
Mower speed
(engine @ 2,850 rpm)
0 ~ 1.6 m/s
+0
–100
00X39VH7F110.book Page 20 Tuesday, November 17, 2009 3:43 PM
