Honda Marine BF15D User Manual

29
ATTACHMENT
INSTALLATION
CLAMP SCREW
WASHER
BOLT
LOCK NUT
MOUNTING HOLE
WASHER
TRANSOM
BOARD
ROPE
If the outboard motor is installed too
low, the boat will squat and be hard
to plane, it will tend to porpoise, and
high-speed stability will be reduced.
If the outboard motor is installed too
high, that will cause ventilation.
Optimum installation height varies
with boat type and bottom shape.
Contact the boat manufacturer for
any special recommendations that are
unique to a specific model of boat.
If the transom needs to be modified
to accommodate the outboard motor,
contact the boat manufacturer and
follow their recommendations for
corrective action.
Attach the stern bracket to the boat
transom by tightening the clamp
screws.
Attach a rope from the boat to the
hole in the stern bracket. This will
help to prevent accidental loss of the
outboard motor.
You may further secure the outboard
motor by bolting the stern bracket to
the boat transom. Use the optional
mounting bolt and nut kit or other
good quality stainless steel bolts, nuts,
and washers. Apply silicone sealant
to the bolt holes.
03/03/24 18:08:23 31ZY0600_030

Honda Marine BF15D Specifications

General

Displacement	350 cc (21.4 cubic inches)
HP Rating	15 HP
Fuel Delivery	Carburetor
Ignition System	Digital CDI
Starting System	Manual or Electric
Gear Ratio	2.08:1
Trim Positions	5
Cooling System	Water Cooled
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane)
Propeller	3-Blade Aluminum
Power Tilt	No
Trim Method	Manual
Engine Type	4-stroke
Full Throttle RPM Range	5000 - 6000 rpm
Exhaust	Through propeller hub
Oil Capacity	1.1 L
Fuel Tank Capacity	12 L
Steering	Tiller
Shaft Length	15 inches / 20 inches
Engine Oil Capacity	1.1 L
Bore and Stroke	59 mm x 64 mm (2.32 inches x 2.52 inches)
