Honda PCX 150 User Manual

Replacing Parts
Always use Honda Genuine Parts or their
equivalents to ensure reliability and safety.
When ordering coloured components, specify
the model name, colour, and code mentioned
on the colour label.
The colour label is attached to the centre
compartment under the seat. 2 P. 64
3WARNING
Installing non-Honda parts may make
your scooter unsafe and cause a crash
in which you can be seriously hurt or
killed.
Always use Honda Genuine Parts or
equivalents that have been designed
and approved for your scooter.
20180912083000_32K97Q000_eng_BOOK Page 77 Wednesday, September 12 2018 08:36:26 JST
Maintenance Fundamentals
Maintenance
72
Colour label

Honda PCX 150 Specifications

General

Displacement	149cc
Bore x Stroke	57.3mm x 57.9mm
Compression Ratio	10.6:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Transmission	Automatic V-Matic
Front Suspension	31mm telescopic fork
Front Brake	Hydraulic disc
Rear Brake	Mechanical drum
Front Tire	100/80-14
Rear Tire	120/70-14
Wheelbase	51.8 inches
Seat Height	30.1 inches
Fuel Capacity	2.1 gallons
Starter	Electric
Front Brake Disc Size	220mm
Rear Brake Drum Size	130mm
Rear Suspension	Twin shock
