Fill the crankcase with the recommended
grade oil; approximately:
Place an oil drain pan under the
crankcase. Remove the oil fill cap/
dipstick, oil drain bolt ( ) and sealing
washer ( ).
Check that the sealing washer on the
drain bolt is in good condition and install
the bolt. Replace the sealing washer
every other time the oil is changed, or
each time if necessary.
Oil drain bolt torque:
Reinstall the oil fill cap/dipstick.
Start the engine and let it idle for 3 5
minutes.
Stop the engine and wait 2 3 minutes.
Check that the oil level is at the upper
level mark on the oil fill cap/dipstick with
the scooter upright on firm, level ground.
Make sure there are no oil leaks.
1.
2.
3.
4.
5.
6.
(1)
(2)
1
2
(1) Oil drain bolt (2) Sealing washer
100
24 N·m (2.4 kgf·m , 18 lbf·ft)
0.8
(0.8 US qt , 0.7 Imp qt)
10/02/17 17:00:40 32KWN600_110
