Honeywell 10282 User Manual

14
LIGHT KIT INSTALLATION
23. To install the fan with a light kit:
Remove the three switch housing screws from the
switch housing cap. Then connect the single-pin
connector from the switch housing to the single-pin
connector from the light kit -- white to white and
black to black (Fig. 23).
Fig. 23
Switch
Housing
Switch
Housing
Screw
Switch
Housing
Cap
Fig. 24
Fig. 25
Switch
Housing
Screw
25. Install the bulbs (Fig. 25).
Important: When replacing the bulb, allow bulb
and light kit to cool before touching.
24. Secure the switch housing cap with light kit to
the switch housing using the previously removed
switch housing screws (Fig. 24).
Socket
Switch Housing
Screw
Switch Housing
Screw
