Light
Pull Chain
INSTALLATION WITHOUT LIGHT KIT
16
Screw Washer
29. Align the notch in the switch housing cap with the
reverse switch. Then lift the switch housing cap
into the switch housing and re-insert the three
screws and washers that were previously removed.
Use a Phillips screwdriver (not included) to secure
all screws (Fig. 29).
Fig. 29
Fig. 28
Switch Housing
Cap
Switch
Housing
Cap
Reverse
Switch
Light Kit
Notch
Hex Nut
Screw
and
Washer
28. (Optional) To install the fan without a light kit:
Unscrew the nut located inside the switch housing
cap from the threaded rod in the center of the cap
to remove the light kit from the switch housing cap
(Fig. 28).
