Honeywell ComfortPoint Open CPO-PC400-W User Manual

CPO-PC400-W/CPO-PC400-UW HVAC CONTROLLER
EN0B-0085 IE10 R0420 4
TECHNICAL DATA
Electrical Data
Power Consumption
Current Consumption
Operational Environment
Default IP Address
Standards
Table 2. CPO-PC400-W/CPO-PC400-UW Electrical Data
Operating Voltage
(AC)
19 to 29 Vac (50/60Hz)
Operating Voltage
(DC)
19 to 29 Vdc
Screw-type Terminals
Conductor cross
section solid
Max. 2.5 mm
2
Overvoltage
Protection
Protected against overvoltages
of max. 29 Vac or 40 Vdc,
terminals protected against
short-circuiting.
Table 3. Power Consumption
Controller
Power
24VAC 24VDC
CPO-PC400-W/
CPO-PC400-UW
Max. 30 VA Max. 14 W
CPO-PC400-W/
CPO-PC400-UW and
CPO-MMI
Max. 35 VA Max. 16 W
Table 4. Current Consumption
Controller
Power
24VAC 24VDC
CPO-PC400-W/
CPO-PC400-UW
Max. 1250 mA Max. 580 mA
CPO-PC400-W/CPO-
PC400-UW and CPO-
MMI
Max. 1450 mA Max. 650 mA
Table 5. CPO-PC400-W/CPO-PC400-UW Operational
Environment
Ambient Operating
Temperature
0 to 50 °C (32 to 122 °F)
Ambient Operating
Humidity
5 to 95% relative humidity
(non-condensing)
Ambient Storage
Temperature
-28.9 to +70°C (-20 to 158 °F)
Ambient Storage
Humidity
5 to 95% relative humidity
(non-condensing)
Vibration Under
Operation
0.024” double amplitude (2 to
30 Hz), 0.6 g (30 to 300 Hz)
Dust, Vibration According to EN60730-1
RFI, EMI Residential, commercial, and
light-industrial environments
MTBF (Mean Time
Between Failure)
11.5 years
Table 6. Default IP Address
IP Address 192.168.0.202
Net Mask 255.255.255.0
Gateway 192.168.0.1
Table 7. Standards
Protection
Class
IP20
Product
Standards
UL60730-1, UL60730-2-9, UL916,
EN60730-1, EN60730-2-9,
CAN/CSA-E60730-1:02
Testing
Electrical
Components
IEC68
Certification cUL60730-1, UL916, CE, BTL B-BC,
BACnet Standard 135 version 1.14,
ISO 16484-5, FCC Part15, Subpart B,
CAN ICES-3 (B)/NMB-3(B), RCM,
AMEV AS-B, KBOB, EAC, RoHS II,
Ethernet Protocol version IEEEC
802.3, EN-1434-3 and EN-13757-3
System
Transformer
The system transformer(s) must be
safety isolating transformers
according to IEC 61558-2-6. In the
U.S.A. and Canada, NEC Class 2
transformers must be used.
Table 5. CPO-PC400-W/CPO-PC400-UW Operational
Environment
