Honeywell HWF2V-COM User Manual

20
RF Specifications
Frequency Bands
LTE
Band 2
LTE
Band 4
LTE
Band 5
LTE
Band 12
LTE
Band 13
WCDMA
Band II
WCDMA
Band V
HWF2V
X
X
X
HWF2A
X
X
X
X
X
X
X
Output Power
LTE Class 3 23dBm
WCDMA
Class 3
24dBm
IMPORTANT NOTE ABOUT EXTERNAL ANTENNAS
Antenna may only be installed or replaced ONLY by a professional installer.
TO THE INSTALLER
HW2FA-COM: The external antenna gain shall not exceed 6.63 dBi for 700 MHz and 850MHz, 6.00 dBi for 1700 MHz, and
8.51 dBi for 1900 MHz. Under no conditions may an antenna gain be used that would exceed the ERP and EIRP power limits
as specified in FCC Parts 22H, 24E and 27.
HW2FV-COM: The external antenna gain shall not exceed 6.94 dBi for 700 MHz 6.00 dBi for 1700 MHz, and 9.01 dBi for
1900 MHz. Under no conditions may an antenna gain be used that would exceed the ERP and EIRP power limits as specified
in FCC Parts 22H, 24E and 27.
Central Station Messages
Alarm Condition
Alarm Code
Restore Code
Power On
/
Reset
E339 C0803
N/A
ECP Supervision (Compromise Indication)
E355 C0000
R355 C0000
Primary Communication Path Supervision
E350 C0951
R350 C0951
Secondary Communication Path Supervision
E350 C0952
R350 C0952
Periodic Cell Comm Path Test Failure
(We do not send a restoral R358 C0803, we send a failure message every day
after the radio attempts to test and fails.)
E358 C0803
N/A
Application Code Update
E903 C08xx
R903 C08xx
(success)
Application Code Update Failure
E904 C08xx
Module Firmware Update
E365 C08xx
R365 C08xx
(success)
Module Firmware Update Failure
E366 C08xx
Trouble Reporting:
The HWF2-COM does not support low/missing battery or AC loss reporting.
Power (low/missing battery or AC loss) is monitored by the PB1 module, which
triggers the trouble buzzer and turns on the appropriate LED. NOTE: Trouble
buzzer sounds during AC Loss only (A Low/missing battery does not trigger
the buzzer).
HWF2-COM communicator fault
The Fire Panel sends out a E380, and E352 message via Telco #1, these are
then relayed to the central station via the HWF2-COM.
Telco line 1 fault
The Fire Panel sends out a E380, and E351 message via Telco #2, these are
then relayed to the central station via the HWF2-COM.
Telco line 2 fault
Fire Panel sends out a E380, and E352 via Telco #1, these are then relayed to
the central station via the HWF2-COM.
E380, E351,
E352 codes as
appropriate.
N/A
Test
5555 5555 9
N/A
AlarmNet Messages
Communication failure. (Possible Compromise Indication)
E359 0 C950
R359 0 C950
Authorized Radio Substitution
00D0 010C 0
N/A
Unauthorized Radio Substitution Attempt
00D0 010E 0
N/A
Service Termination
00D0 020E 0
N/A
