Honeywell LYNX Touch 5100 User Manual

- 18 -
Zone Programming Worksheet
Zone
No.
Loop
No.
Device
Type
Response
Type Report Chime Supervision
Transmitter
Serial Number
Zone
Descriptor
45
46
47
48
49 3 4 Button (Key) Arm Away Yes No Button N/A
50 2 4 Button (Key) Disarm Yes No Button N/A
51 4 4 Button (Key) Arm Stay Yes No Button N/A
52 1 4 Button (Key) No Response No No Button N/A
53 3 4 Button (Key) Arm Away Yes No Button N/A
54 2 4 Button (Key) Disarm Yes No Button N/A
55 4 4 Button (Key) Arm Stay Yes No Button N/A
56 1 4 Button (Key) No Response No No Button N/A
57
58
59
60
61
62
63
64
80 N/A Temperature Not used Yes No High Temp N/A
81
N/A
Temperature Not used Yes No Low Temp
N/A
82
N/A
Temperature Not used Yes No High Temp
N/A
83
N/A
Temperature Not used Yes No Low Temp
N/A
84
N/A
Temperature Not used Yes No High Temp
N/A
85
N/A
Temperature Not used Yes No Low Temp
N/A
95
N/A
Fire Fire No Verif. Yes No Panic Trigger
96
N/A
Medical Not Used Yes No Panic Trigger
97
N/A
N/A Yes No Cover Tamper
N/A
99
N/A
Police 24 Hour Silent Yes No Panic Trigger
Explanation of Zone Assignment Table Headings
Loop Number - Used with 5800 Devices. Record transmitter loop number. Entries are 1-4, depending on device being used. Refer to the
transmitter’s instructions or the figure provided for appropriate loop numbers.
Device Type- Dependant upon the Zone Number being programmed.
Door Smoke Detector Flood Fire
Window Heat Sensor Environmental Other
Motion Sensor Carbon Mono. Det. Medical
Glass Break Temperature Police
Response Type - Dependant upon the Device Type that has been selected.
Entry Exit 1 24 Hour Audible Trouble Resident Monitor
Entry Exit 2 24 Hour Auxiliary Arm Stay Resident Response
Perimeter Fire No Verification Arm Away General Monitor
Interior Follower Interior with Delay Disarm General Response
Day/Night Monitor No Response Fire With Verification
24 Hour Silent Carbon Monoxide Silent Burglary
Supervision - Dependant upon the Zone Number being programmed.
Hardwire Zone (Zone 1) Wireless Zone (Zone 2-48) Key (Zone 49-64) Temperature (Zone 80-85)
End of Line (Resistor) Supervised Button High Temp
Normal-Closed Unsupervised Low Temp
Normal-Open
