PRO 1000 Series
3
ENGLISH
Quick reference to display
* If Heat On or Cool On is flashing, compressor protection is engaged (see page 7).
** Applies to TH1210D model only.
Temperature display
The ambient (measured)
temperature is normally
displayed. To view the
setpoint temperature, press
either of the temperature
adjustment buttons once.
The setpoint temperature
will appear for five seconds.
System Status
• Cool On: Cooling is activated. *
• Heat On: Heating is activated. *
• Aux On: Auxiliary heat is activated. **
Low-battery warning
(see page 8)
Setpoint indicator
Appears when the setpoint
temperature is displayed.
400-626-002-D (69-1971EFS-04 non-prog TH1110D_TH1210D user manual) USA.book Page 3 Tuesday, September 8, 2009 10:31 AM
