Honeywell RIO User Manual

5. Secure the mounting bracket to the outlet box using
screws and washers provided with the outlet box
(not included) (Fig. 5).
Note: It is very important that you use proper hardware
when installing the mounting bracket as it supports
the fan.
Important: If using the angle mount, ensure that the
open end of the mounting bracket is installed facing
the peak of the ceiling.
Fig. 4
Fig. 5
Mounting
Bracket
Canopy
Washer
Mounting
Bracket
Screws
4. Loosen all four mounting bracket screws. Remove
the two mounting bracket screws and washers from
the round holes of canopy. Set aside for later use.
Detach mounting bracket from canopy (Fig. 4).
Mounting Bracket
Screw
Washer
6
MOUNTING BRACKET INSTALLATION

Honeywell RIO Specifications

General

Brand	Honeywell
Model	RIO
Category	Fan
Language	English
