Honeywell VQ400M Series User Manual

EN2R--9018 9704R1--NE
5
Table 1. Power consumption (W) main valve VQ400 Series
M
o
d
e
l
360 mbar 200 mbar
Model
220 ... 240 Vac 100/110 Vac 24 ... 28 Vdc 220 ... 240 Vac 100/110 Vac 24 ... 28 Vdc
V1 V2 V1 V2 V1 V2 V1 V2 V1 V2 V1 V2
F S F S F S F S F S F S
VQ420Ax 14 14 14 14 14 14 17 17 17 14 14 14 14 14 14 17 17 17
VQ425Ax 20 20 20 18 18 18 24 24 24 20 20 20 18 18 18 24 24 24
VQ440Ax 41 41 41 48 48 48 64 64 64 40 40 40 47 47 47 67 67 67
VQ450Ax 60 60 60 65 65 65 67 67 67 41 41 41 48 48 48 64 64 64
Table 2. Power consumption (W) additional valves
Additional
v
a
l
v
e
360 mbar 200 mbar
valve
220 ... 240 Vac 100/110 Vac 24 ... 28 Vdc 220 ... 240 Vac 100/110 Vac 24 ... 28 Vac
3/4” 1” 3/4” 1” 3/4” 1” 3/4” 1” 3/4” 1” 3/4” 1”
by--pass valve 14 20 14 18 17 24 14 20 14 18 17 24
pilot valve 14 -- 14 -- 17 -- 14 -- 14 -- 17 --
vent valve 14 -- 14 -- 17 -- 14 -- 14 -- 17 --
