PG.5
OPERATION
Additional accessories available for
purchase at Hoover.com
General Maintenance
Avoid using solvents when cleaning plastic parts. Most plastics
are susceptible to damage from various types of commercial
solvents and may be damaged by their use. Use clean cloths to
remove dirt, dust, oil, grease, etc.
This product contains no serviceable parts.
If appliance is not working as it should, has been dropped,
damaged, left outdoors or dropped in water, contact customer
Emptying the Dirt Cup
See Figure 7, page 8
• Remove the battery pack.
• Push down the latch on the dirt cup to release. Tilt and lift to
remove the dirt cup from the stick vac.
• Hold the dirt cup over a trash bin and press the dirt cup re-
lease button to empty.
• To close, push the door until it locks back into place.
• Replace the dirt cup by rocking it back into place.
Cleaning the Filter and Cyclone
See Figure 8, page 9
•
• To clean the cyclone, lift to remove. Clean dirt and debris by
wiping the metal screen with a cloth and then place back
into the dirt cup.
•
Removing and Replacing the Brush Roll
See Figure 9, page 9
• Remove the battery pack.
• Remove powered nozzle from reach wand. Using a coin,
push and turn the brush roll lock counterclockwise to re-
lease the brush roll.
• Pull the brush roll out of the powered nozzle
• To remove any threads or hair, slide the blade of a pair of
scissors into the groove of the brush roll and cut along
the groove. Clear any dirt/debris from the end caps and
inside the housing of the powered nozzle.
•
roll lock clockwise to lock.
For troubleshooting, please visit Hoover.com
Thermal Protector
A thermal protector has been designed into your cleaner
to protect it from overheating. When the thermal protector
activates, the cleaner will stop running. If this happens,
proceed as follows:
1. Turn cleaner OFF and remove battery pack
2. Empty dirt cup
3.
obstructions if present
4. When cleaner is unplugged and motor cools for 30
minutes, the thermal protector will deactivate and cleaning
may continue
If thermal protector continues to activate after following
MAINTENANCE
To avoid serious personal injury, always remove the
battery pack from the product when cleaning or
performing any maintenance.
based products, penetrating oils, etc., come in contact with
plastic parts. Chemicals can damage, weaken or destroy
plastic which could result in serious personal injury.
WARNING!
WARNING!
To avoid injury, particularly to face and head, keep
away from revolving brush.
WARNING!
WARNING!
the product.
WARNING!
Do Not use accessories for grooming a pet.
CAUTION!
