13
HOSE: How to Clean
4.16
A
To reduce the risk of personal injury - Unplug before cleaning or servicing.
4.16 To remove hose for tool use, press the hose release button (A) and pull
hose end out.
Clear away debris or obstructions from hose. Do not use sharp objects to clean
out hose as they can cause damage. To lock back into place, push hose into
hose tube until you hear a click.
4.20
4.21
4.22
Removing Lens
Press Handle Release Pedal and place handle in
low position.
4.20 Using a Phillips screwdriver, remove (2) screws
as shown and lift off lens.
Installing Bulb
4.21 Pull old bulb straight out of socket. Push new
bulb straight into socket until locked in place.
Do not use excessive force when installing bulb.
Do not twist or turn bulb when installing bulb.
Replacing Lens
4.22 Reposition lens and secure with screws.
What to Buy:
Headlight
Additional bulbs may
be ordered at Hoover.
com or call 1-800-
944-9200. Ask for
Hoover
®
Part No.
27313-107.
HEADLIGHT: How to Replace
WARNING
! !
To reduce the risk of electric shock - Unplug
before cleaning or servicing.
(available on select models only)
WARNING
! !
4.19
4.17
4.17 Clean the Turbo Tool by removing the two
screws (A), located on the bottom cover, with a
Phillips head screwdriver.
4.18 Remove the bottom cover (B).
Clean out any debris or hair from the brushroll
and turbine fan.
4.19 Replace the bottom cover, insert and tighten
the (2) screws.
A
TURBO TOOL: How to Clean
(Tool varies per model)
4.18
CAUTION
! !
To reduce the risk of injury from moving parts -
Unplug vacuum before servicing.
B
