4. Remove the Phillips PM2.0×10.7 screw (2) that secures the optical drive to the computer.
5. Remove the optical drive (3).
Reverse this procedure to install the optical drive.
Bottom cover
Description Spare part number
Bottom cover 926832-001
Before removing the bottom cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the optical drive (see Optical drive on page 35).
Remove the bottom cover:
1. Remove the computer rubber feet (1).
The rubber feet are available using spare part numbers 926855-001
36 Chapter 5 Removal and replacement procedures
