Display assembly
This section describes removing the display assembly in its entirety and disassembling all the display
subcomponents.
If you only need to remove the display bezel, webcam/microphone module, or display panel, you do not need
to remove the entire display assembly from the computer. See
Display subcomponents (bezel, webcam,
panel) on page 49 for more information about removing the display subcomponents that do not require that
you remove the entire display assembly from the computer.
Description Spare part number
Raw display panel
Non-touch screen for use in all models 750635-001
Touch screen for use in HP 15 models 764877-001
Touch screen for use in Compaq 15 models 764876-001
Antennas
For use in models without a touch screen (includes wireless antenna cables and transceivers) 749638-001
For use in models with a touch screen (includes wireless antenna cables and transceivers) 774163-001
Display bezel
For use in HP 15 models 749644-001
For use in Compaq 15 models 749645-001
Display cable
For use in non-touch screen models (includes display panel cable and webcam/microphone cable) 749646-001
For use in touch screen models (includes display panel cable and webcam/microphone cable) 764888-001
Display enclosure, touch screen models
Black licorice/textured HP 15 models 774164-001
Sparkling black HP 15 models 775086-001
Blue HP 15 models 775084-001
Silver HP 15 models 775085-001
White HP 15 models 775083-001
Red HP 15 models 775082-001
Gray HP 15 models 775081-001
Purple HP 15 models 779336-001
Gray Compaq 15 models 775079-001
Black Compaq 15 models 775080-001
Purple Compaq 15 models 779411-001
Display enclosure, non-touch screen models
Black licorice/textured HP 15 models 749641-001
Sparkling black HP 15 models 761695-001
Component replacement procedures 77
