HP 15 TouchSmart Notebook PC User Manual

WLAN module
Description Spare part number
Atheros AR9485 802.11b/g/n 1x1 WiFi Adapter 675794-005
Realtek RT8723BE 802.11bgn 1x1 Wi-Fi and Bluetooth 4.0 combination adapter 753077-005
Atheros AR9565 802.11bgn 1x1 WiFi + BT4.0 combo Adapter 733476-005
Realtek RTL8188EE 802.11bgn Wi-Fi Adapter 709848-005
Broadcom BCM43142 802.11 bgn 1x1 Wi-Fi + BT4.0 HMC Combo Adapter 753076-005
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless module
authorized for use in the computer by the governmental agency that regulates wireless devices in your
country or region. If you replace the module and then receive a warning message, remove the module to
restore device functionality, and then contact support.
Before removing the WLAN module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 35).
5. Remove the keyboard (see
Keyboard on page 39).
6. Remove the top cover (see
Top cover on page 47).
To remove the WLAN module:
1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The #1 WLAN antenna cable is connected to the WLAN module Main terminal. The #2 WLAN
antenna cable is connected to the WLAN module Aux terminal.
2. Remove the Phillips PM2.0×3.0 screw (2) that secures the WLAN module to the system board. (The
WLAN module tilts up.)
Component replacement procedures 55

HP 15 TouchSmart Notebook PC Specifications

General

Touchscreen	Yes
Display	15.6-inch
Display Resolution	1366 x 768
Graphics	Intel HD Graphics
Wireless	802.11b/g/n
Ports	USB 3.0, HDMI, Ethernet, SD card reader, headphone/microphone combo jack
Optical Drive	DVD-RW (varies by model)
Battery	4-cell Li-ion
