Table 3-1 Computer major component descriptions and part numbers
Item Component Spare part number
(1) Display assembly
NOTE: Display assemblies are oered as spare parts only at a subcomponent level. For more
information, see Display assembly subcomponents on page 18.
not available as a
spare part
(2) Keyboard/top cover
For a detailed list of country codes, see Top cover with keyboard on page 53.
Natural silver, ngerprint reader, backlit M08910-xx1
Natural silver, ngerprint reader, not backlit M08911-xx1
Natural silver, no ngerprint reader, backlit M08912-xx1
Natural silver, no ngerprint reader, not backlit M08913-xx1
Cloud blue, ngerprint reader, backlit M08918-xx1
Cloud blue, ngerprint reader, not backlit M08919-xx1
Cloud blue, no ngerprint reader, backlit M08920-xx1
Cloud blue, no ngerprint reader, not backlit M08921-xx1
Luminous gold, ngerprint reader, backlit M08922-xx1
Luminous gold, ngerprint reader, not backlit M08923-xx1
Luminous gold, no ngerprint reader, backlit M08924-xx1
Luminous gold, no ngerprint reader, not backlit M08925-xx1
Light teal, ngerprint reader, backlit M08926-xx1
Light teal, ngerprint reader, not backlit M08927-xx1
Light teal, no ngerprint reader, backlit M08928-xx1
Light teal, no ngerprint reader, not backlit M08929-xx1
(3) Power connector (DC-in) cable M08887-001
(4) Touchpad
NOTE: The touchpad cable is available using spare part number M08876-001.
Fog blue M08872-001
Forest teal M08873-001
Natural silver M08874-001
Warm gold M08875-001
(5) Fingerprint reader
NOTE: The ngerprint reader cable is available using spare part number M08883-001.
Fog blue M08878-001
Forest teal M08879-001
Natural silver M08880-001
Warm gold M08881-001
16 Chapter 3 Illustrated parts catalog
