Connector repair
This procedure includes HDMI and D-SUB connectors.
The connectors are on the main board (board part number CBPRNE7HPQ6).
The connectors identifiers are as follows:
Connector
Location
HDMI
CN503
D-SUB
CN101
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 12.
Main Board
CN101
CN503
